Hazardous Locations

HT-SERIES It is a luminaire designed for hazardous applications, its innovative vertical flow cooling design allows its operation in harsh environments of extreme heat with temperatures up to 70°C, such as metal smelting facilities, iron forges, steel mills, power generation , factories and chemical plants.

To Series

key features

1. vertical heatsink

Vertical heatsink design, allows wide operating temperature from -40° to 70°C

2. IP67 protection

Hermetic body with IP67 protection

3. Ring

Ring (included for 80W / 100W / 150W models)

4. multi-voltage input

100-277 V~ or 347-480 V~

5. Power supply

Dimmable 0-10V

6. rotatable bracket

Included for 200W / 300W / 400W / 500W / 600W models

SPECS

eight models

80W

80W
12,000lm

100W

100W
15,000lm

150W

150W
22,500lm

200W

200W
30,000lm

300W

300W
45,000lm

400W

400W
60,000lm

500W

500W
75,000lm

600W

600W
90,000lm

Luminous Efficacy

150lm/W

Input voltage

100 – 277 V~ / 347 – 480 V~

dimmable

0-10V

Color Temperature

5000K

irc

>80

Optics

Borosilicate

Opening angle

120°

Operating Temperature

-40 to 70°C

Mounting

Ring (included):
80W/100W/150W
Rotatable bracket (included):
200W/300W/400W/500W/600W

CUSTOMIZE YOUR LUMINAIRE

guide to order

1

Series

EXHT –HT-Series

2

Model

80W – 12,000lm
100W – 15,000lm
150W – 22,500lm
200W – 30,000lm

300W – 45,000lm
400W – 60,000lm
500W – 75,000lm
600W – 90,000lm

3

Power supply

1 – 100 – 277 V~
2 – 347 – 480 V~

Example: EXHT-150W-2 (A Series, 150W, 22500 lm, 5000K, 347 – 480 VAC, 120° Borosilicate Optics, For high ambient operating temperatures from -40ºC to 70ºC)

Dimensions per body

80W

12,000lm

100W

15,000lm

150W

22,500lm

200W

30,000lm

300W

45,000lm

400W

60,000lm

500W

75,000lm

600W

90,000lm

Certifications & Guarantees

UL 1598
UL 1598A

EN
