Lighting - High & Low Bay
SP9.5
Sports Light
The SP9.5 is an ultra-high performance stadium luminaire featuring a quick-change lens system and a 3-in-1 configuration with color temperature (CCT) and power selection. Designed for installation flexibility, it is compatible with U-bracket, top bracket and SF bracket mounting options. To optimize light control and uniformity, the luminaire is available in visor or louvre configurations.
IP66 Splash resistant
IK08 Impact resistant
160LM/W
Luminous Efficiency
Overview
Dimensions
Technical data
Luminous Efficiency
160LM/W
Optics
Polycarbonate
Opening angle 20°, 30°, 45° or 60°.
Luminous flux
Max. 80,000lm
Easily adjust the power of your luminaire in the field.
Venus V4 has a power switch that allows you to easily adjust the power of your luminaire at any time, adapting it to your environment and height.
Durability and Resistance
With an IP65 rating, Venus is immune to dust and water, IK08 impact resistance, and is robust against the most demanding conditions. In addition, it is equipped with surge protection up to 4 kV.
Stay illuminated in unexpected situations.
Venus V4 is compatible with an emergency battery that allows the luminaire to operate for a minimum of 90 minutes. It has two operating powers (25W / 40W).
| Luminous efficacy | 160 LM/W |
| Input voltage | 110 - 277 V~ (Multivoltage) |
| Dimmable | 0 - 10 V |
| IRC | >70 |
| Beam Angle | 20°, 30°, 45°o 60° |
| Operating temperature | -40 to 50 °C |
| Mounting | U-shaped bracket, Upper arm, SF type bracket |
| Optics | Polycarbonate |
| Protection | IP66 |
| Resistance | IK08 |
