Street Light

Outdoor luminaire designed for urban applications, be it streets, avenues, highways, etc. COBRA HEAD LIGHT It has an incredible versatility of nominal powers, with 13 different models.

Cobra Head Light

key features

1. Aluminium alloy

Made of die-cast A383 aluminum alloy

2. Mounting

Fitting compatible with tubes with a diameter of 50-60 mm

3. Easy access

Easily accessible tool-free clips and solder-free electrical connection

4. stabilizer bubble

included

5. Protection

Protection against voltage peaks of 10 kV (protects the power supply and the LED card)

6. Maintenance

Designed for easy cleaning, prevents accumulation of dust and bird waste

7. trapezoidal system

Trapezoidal system that allows to adapt the mounting angle on the pole (±5°)

8. IP66 protection

IP66 protection, makes it waterproof and dust free

9. durable finishes

Durable anodized and powder-coated finish with epoxy paint and heat treatment to ensure long-term environmental protection

10. photocell

Compatible with the Photocell, energy saving sensor

SPECS

thirteen models

The Serie COBRA HEAD LIGHT is one of the most versatile luminaires on the market, it has THIRTEEN different models:

4K

30W
3.9k

5K

40W
5.2k

6K

50W
6.5k

8K

60W
7.8k

9K

70W
9.1k

10K

75W
9.75k

12K

90W
11.7k

13K

100W
13k

14K

110W
14.3k

15K

120W
15.6k

17K

135W
17.55k

19K

150W
19.5k

21K

165W
21.45k

Luminous Efficacy

130lm/W

Input voltage

100 – 277V~

Color Temperature

3000K
4000K
5000K

irc

>70

Optics

polycarbonate

Opening angle

Type II
Type III
Type IV

Operating Temperature

-20 to 50°C

Mounting

50 – 60mm
(pole diameter)

CUSTOMIZE YOUR LUMINAIRE

guide to order

1

Series

CH – Cobra Head Light

2

Model

4K – 3,900lm
5K – 5,200lm
6K – 6,500lm
8K – 7,800lm
9K – 9,100lm

10K – 9,750lm
12K
– 11,700lm
13K
– 13,000lm
14K – 14,300lm
15K – 15,600lm

17K – 17,550lm
19K – 19,500lm
21K – 21,450lm

3

Color Temperature

30 – 3000 Kelvin
40 – 4000 Kelvin
50 – 5000 Kelvin

4

Optics

1 – Type II Polycarbonate
2 – Type III Polycarbonate
3 – Type IV Polycarbonate

5

Control

No. - Neither
P – Photocell
Yo – Enabled for
JUNGO ConnectⓇ

Example: CH-10K-50-1-I (Cobra Head Light, 10K 75W, 9750 lm, 5000K, Type II Polycarbonate Optics, JUNGO ConnectⓇ Enabled)

Example: CH-21K-30-3-N (Cobra Head Light, 21K 165W, 21450 lm, 3000K, Type IV Polycarbonate Optics, Dimmable 0-10V)

CH-4K-40-1-P
CH-5K-40-1-P
CH-6K-40-1-P
CH-8K-40-1-P
CH-12K-40-1-P
CH-13K-40-1-P
CH-14K-40-1-P
CH-15K-40-1-P
CH-17K-40-1-P
CH-19K-40-1-P

Dimensions per model
(lumens)

4K/5K/6K/8K/9K/10K

2.1kg

12K / 13K / 14K / 15K / 17K / 19K / 21K​

2.9kg

Compatible Product

Cobra Head Light

photocell

Photocell JL-215-C

Certifications & Guarantees

NOM-003-SCFI-2014
NOM-031-ENER-2012
